Light Rails For Mining Uses. It follows the standards of China's national stand: GB11264/89, stable with compentitive prices.
Besides, every time we could provide the weight list to ensure the error between the weight of clients requested and the actual weight provide
is within a reasonable range.
___________________________________________________________________________________________________________________
Rieles ligeros para usos mineros. Sigue los estándares del soporte nacional de China: GB11264/89, estable con precios competitivos.
Además, siempre podemos proporcionar la lista de peso para garantizar el error entre el peso solicitado por los clientes y el peso real proporcionado.
está dentro de un rango razonable.
|
Size
|
Dimension(mm)
|
Weight
(kg/m)
|
Material
|
Length(m)
|
|
Head(mm)
|
Height(mm)
|
Bottom(mm)
|
Weight(kg/m)
|
|
GB6KG
|
25.4
|
50.8
|
50.8
|
4.76
|
5.98
|
Q235B
|
6-12
|
|
GB9KG
|
32.1
|
63.5
|
63.5
|
5.9
|
8.94
|
Q235B
|
6-12
|
|
GB12KG
|
38.1
|
69.85
|
69.85
|
7.54
|
12.2
|
Q235B/55Q
|
6-12
|
|
GB15KG
|
42.86
|
79.37
|
79.37
|
8.33
|
15.2
|
Q235B/55Q
|
6-12
|
|
GB22KG
|
50.3
|
93.66
|
93.66
|
10.72
|
22.3
|
Q235B/55Q
|
6-12
|
|
GB30KG
|
60.33
|
107.95
|
107.95
|
12.3
|
30.1
|
Q235B/55Q
|
6-12
|
For More Information,please contact us.
